LG-55inch-3.8mm 800 nit LCD Video Wall Screen

  • Model Number:   MPJ55LHX38
  • Brand Name:   Marvel
  • Certification:   CE FCC ROHS
  • Place of Origin:   Shenzhen, China
  • Application:   Indoor
  • Input Voltage:   AC100~240V 50 /60 HZ
  • Packaging:   Bubble bag+packing foam+carton+wooden case
  • Delivery Detail:   Batch order 15-30 days

  1. Detailed information
  2. Video
  3. Pic

 Video Wall Screens With LED Backlight



Detailed Product Description



Installation Types: Press and Eject viseo wall bracket, Wall Mounted, Floor standing, Cabinet floor satanding





Panel



Panel Size

55 inch LG  LCD Screen (with narrow bezel 3.8mm)

Splice bezel
3.8mm

Aspect Ratio

16:09

Max Resolution Support

1920×1080(H×V)

Color

8Bit,16.7M

Brightness (nits)

800

Contrast

4000:01

Visual Angle (H/V)

178°(H) / 178°(V)

Response Time

6ms

Life(hrs)

>60,000(hrs)

Input and output



DVI

1

HDMI

1

D-15 RGB Input(VGA)

1

YUV/YPbPR

1(3xBNC)

S-(YC)

1(2xBNC)

Composite Video Input/(AV)

3(3xBNC)

Composite Video Output

2(2xBNC)

AUDIO INPUT

1

Split Screen

Support Picture in Picture(PIP/POP/PAP)

Power



Power Supply

AC100V~240V

Maximum Power Consumption

230W

Standby Power Consumption

<=3W

Working Temperature

0°C~50°C

Working Humidity

20%-80%

Video Wall Processor Controller



Model No.

MV-P817W

DVI in

1

HDMI in

1

VGA in

1

Composite Video Input/(AV)

1(BNC)

Composite Video Output

1(BNC)

Control signal input and loop out

RS232(RJ45-8)

Split Screen

Sport Picture in Picture (PIP/POP)

power consumption

Max 300W,according to different Screen models

Dimension

338×295×60(mm)

Weight

 3.5-4.0kg




TAG:  Full HD LCD Video Wall   Video Wall   LCD Touch Screen Video Wall   Full HD Video Wall
